| 参数 | 规格 | 单位 | |
| ITU Grid (C and L Band) | nm | ||
| 通道带宽 | λc + 0.11/0.125 (minimum) | λc + 0.25(minimum) | nm |
| 通道间隔 | 100 | 200 | GHz |
| 通道平坦度 | ≤ 0.4 | ≤ 0.4 | nm |
| 插损 | ≤ 1.6 (2 Channel) | ≤ 1.6 (2 Channel) | dB |
| ≤ 2.4(4 Channel) | ≤ 2.4(4 Channel) | dB | |
| ≤ 2.5 (8 Channel) | ≤ 3.2 (16 Channel) | dB | |
| ≤ 3.5(16 Channel) | ≤ 3.5(16 Channel) | dB | |
| 相邻信道隔离度 | ≥ 30 | dB | |
| 不相邻信道隔离度 | ≥ 45 | dB | |
| 插损温度 | ≤ 0.005 | dB/℃ | |
| 偏振相关损耗 | ≤ 0.1 | dB | |
| 偏振模式色散 | ≤ 0.1 | ps | |
| 回损 | ≥ 45 | dB | |
| 方向性 | ≥ 55 | dB | |
| 工作温度 | 0 to 70 | ℃ | |
| 储存温度 | -40 to 85 | ℃ | |
| 封装尺寸 | 80 (L) x 58 (W) x 6.6 (H) | mm | |
